GE DS200FGPAG1ALD Gate Pulse Amplifier Board 330mm x 200mm

GE DS200FGPAG1ALD LCI GATE PULSE AMPLI

Product Details:

The GE DS200FGPAG1ALD is a Gate Pulse Amplifier Board designed for SCR (Silicon-Controlled Rectifier) bridge systems, with core roles including delivering power to one SCR bridge phase, collecting cell voltage data, and converting AC to DC control voltage. It is optimized for industrial environments, featuring a fiber optic communication setup—1 sending port and 14 receiving ports—to enable fast, stable data transmission.

Two receiving ports support duplex fiber optic networks, while the rest serve simplex networks. Fiber optics eliminate electrical interference, allowing coexistence with 3-phase power cables, and offer longer transmission ranges than copper. Cable routing requires adhering to specified bend radii to avoid transmission degradation or cable damage, and signal power can be adjusted based on cable length and other factors.

Key Features
SCR Bridge Integration: Delivers phase-specific power to SCR bridges, collects cell voltage data, and converts AC to DC control voltage—critical for regulating SCR-based power conversion systems.

Interference-Free Fiber Optic Communication: 1 send/14 receive ports enable robust data transfer; fiber optics resist electrical interference, supporting safe use near power cables and ensuring signal integrity in industrial settings.

Extended Transmission Capability: Outperforms copper in range, with up to two repeaters doubling length each time, adapting to large industrial layouts.

Configurable Signal Power: Allows adjustment of signal power based on cable length and system needs, optimizing transmission efficiency for diverse industrial setups.
