GE 531X179PLMAKG1 Power Line Monitor 100mm x 200mm

The GE 531X179PLMAKG1 is a Power Line Monitor, the circuit board designed to monitor power line operations in industrial systems. Manufactured by General Electric, it features a range of components tailored for power monitoring and signal control: a central line of 7 red and 1 green LEDs for status indication, two small transistors, variously sized capacitors to store energy via electrical fields, four small blue variable resistors each controlling low energy levels, and numerous diodes regulating current direction.

It also includes two blue boxes with five numbered buttons for manual control, eight integrated circuits, multiple fixed resistors, a fuse, and a mix of female/male terminals for system connection. These components work together to track power line conditions and ensure stable energy flow, though its discontinuation means it is no longer produced for modern industrial setups.

Key Features
Power Monitoring Focus: Engineered to monitor power lines, with dedicated components for current regulation, energy storage, and low-energy control—critical for tracking power line stability.

Status Visibility: A central line of 8 LEDs provides clear visual feedback on operational status, simplifying real-time monitoring and troubleshooting.

Manual Control: Two blue boxes with numbered (1–5) “OFF” buttons enable manual adjustment of specific functions, adding flexibility for operator intervention.

Data Storage: Eight ICs store all operational information, ensuring the board executes its monitoring logic consistently.

System Compatibility: Mix of female/male terminals facilitates secure connection to industrial systems, while a fuse adds protection against electrical faults.
